BLUE CRATE ENGINE
AND TURNKEY 4 X 4
FORD 302 — 252+
Bronco I: Ford 302 — 252 HP
Bronco II: Ford 302 — 272 HP
Bronco III: Ford 302 — 292 HP
Bronco IV: Ford 302 — 302
Bronco V: Ford 302 — 322
(ALSO: ASK ABOUT OUR 1978 AND UP BRONCO ENGINES: 302 AND 351 WINDSOR ENGINES!!)
Ford 302 — 252 HP (Bronco
I) from $2595
(torque range 280 - 287 ft lbs)
Ford 302 — 272 HP (Bronco II) from $2695
(torque range 302 - 312 ft lbs)
Ford 302 — 292
HP (Bronco III) from $2895
(torque range 337 - 342 ft lbs)
Ford 302 — 302
HP (Bronco IV) from $3095
(torque range 344 - 351 ft lbs)
Ford 302 — 322 HP (Bronco
V) from $3295
(torque range 348 - 357 ft lbs)
A "Crate Engine" means "Intake
to Pan." Just give us a call if you'd like
this engine in a TURNKEY package!
Turnkey packages start from
$995 to $1095 to $1195 to $1295 to $1395 additional cost for this crate engine.
about our Fast Track Startup:
That means this engine can be Real
Ready to Run OUT OF THE BOX if
you choose our Fast Track startup, which includes
break in, super tuning, jetting, and more.
you choose a Fast Track Start Up, we
have special pricing right now!
HERE to learn more
FAST TRACK, and
view a sample video.
This is one of the best mild street
engines around for BRONCOs 1966 and up to 1977;
For Streets and 4 x 4s, Ford custom trucks, 4 X 4s, & JEEPS.
This Power 1® Engine
Combination would be great as a replacement mild
This engine has a MILD
idle, SPEED PRO CAM that puts out 252 HP 800 rpm to
4500 and 300 ft lbs of torque. Hydraulic flat tappet
cam for low end and midrange power. You will NOT
need a stall speed convertor. This will be a excellent
engine for an everday Driver.
features on this crate engine include these
new parts and more: (Be sure to scroll
down the page to see a more detailed listing.)
This engine is a seasoned block, hand picked
POWER SL HEAVY DUTY PISTONS
Compression pistons is 8.5 to
Higher HPs are 9.5 to 1 for pump gas.
Ford cast iron heads with hardened exhaust
seats. Also available as an upgrade are the GT40 and the GT40 P heads.
STEEL FORGED RODS 302 Ford Bronco rods
Pro Turn micro polished
New Satin Aluminum intake
Polished RPM dual plane intake manifold is extra.
This engine comes assembled with rear sump
Chrome valve covers
New aluminum timing
New P.E.R. HP harmonic
Engine will run on premium unleaded fuel
Built from one of our Dyno tested and road proven packages. Your specific engine can be Dyno tested for an additional charge.
Call for info on flex plate or fly wheel.
Call for correct flex plate on automatics.
Call for info on standard transmissions (4, 5, or 6 speed, etc.)
Comes complete, intake to oil pan. Some assembly may be needed.
What comes with your Power 1 ® engine?
Here's a listing of the parts and machine labor for
Power 1 ® engine from PhoenixEngine.com.
Your Power 1 Engine® ENGINE
- Power 1® Speed Pro or Comp cam kit GREAT
POWER AND SOUND FOR YOUR BRONCO!
- Power 1® Seal Power hydraulic lifters
- Power 1® spring
set, heavy duty (940, series spring sets)
- New satin aluminum intake manifold (Polished
RPM dual plane intake manifold is extra).
- HD Stem steel intake valves
- HD Stem steel exhaust valves
- Premium positive valve
- Heavy duty roller timing chain
- Controlled internal oil system (a P.E.R.
- Heavy duty High Melling volume oil pump
- Heavy duty
Melling steel collar oil shaft
- Heavy duty oil pickup
- High quality Seal Power SL Heavy duty pistons
- P.E.R.® Seal Power HP plasma molly rings
freeze plug kit, oil gallery plug kit
- High quality
rear main seal, double lip polyacrylate
- Fel Pro PermaTorque
heavy duty gaskets and gasket set
- King or Clevite Main bearings,
King Tri metal, high quality
- King or Clevite Rod bearings,
King Tri metal, high quality
- New ARP rod bolts & nuts
- Cam bearings, high quality 360 Set
Your Power 1 Engine® MACHINE
- P.E.R. 3-angle® valve job
- Heavy duty thick wall valve
- Valve guides custom cut for posi-seals
- Jet vat block and magnifluxing
- Remove and
replace all freeze plugs
- Remove and replace
- Remove and replace cam bearings
- Custom centerline boring of block
degree V8 centerline Boring
- Power hone to
fit pistons and rings
- Custom crank Micro polished
radius oil holes
- Rods pressed off, then heat
- Rods checked for alignment
- Street balancing
We Dyno'd this engine (original) with Edelbrock 600
cfm, and an Edelbrock AVS 4x4 carb, Holley 600 and 670 cfm Street Avenger carb for four
wheel and mild street. All did very well on pump gas.
ASK US ABOUT OUR CARB and ELECTRONIC DISTRIBUTOR PACKAGE
FOR THIS TYPE OF POWER ENGINE
Engine comes completely assembled, intake to oil pan.
ASK US ABOUT OUR TURN KEY PACKAGE FOR THIS
TYPE OF POWER ENGINE.
For any changes needed,
just call and we will build a custom engine package
for you with the horsepower you want. You can also
change the color, choosing from over 25 different
OUR ENGINES ARE CUSTOM HAND BUILT:
289 - 302 - 351c - 351m - 351w - 400m 390 - 427-
428 - 429 - 460
Call to order this engine:
Toll Free 1-888-766-8044
08:00am - 5:00pm Monday - Friday
09:00am - 1:00pm Saturday
Times listed are Arizona time (-7 GMT).
Arizona does not observe Daylight Savings Time. We are on MST all year
This Power Engine®
is totally REBUILT in our Machine Shop by professionals
from start to finish. The Power Engine®
Performance Combination was developed from our over
45 years of experience on MUSCLECARS, STREET STRIPS,
CUSTOM TRUCKS, 4x4s, and JEEPS. PhoenixEngine.com has
built over 140,000 quality engines to date.
Warranty and Shipping Info:
This engine has a
one year written warranty. Buyer pays actual shipping
costs if unable to pick up engine from our shop
in Phoenix AZ. Some state freight restrictions
apply. Payment due in full prior to shipping. We
accept Visa, Mastercard, Discover, money orders, cashier's
checks, and direct deposit. (GET
A DISCOUNT WITH A DIRECT DEPOSIT!) Business
or personal checks must clear prior to shipping.
Arizona residents must add 8.6% sales tax.
Please call for core requirements.
SPECIAL PROMO!! Call NOW
for FREE SHIPPING to Southern California! We also
offer super shipping rates to all 48 continental states.
today to order!
Toll Free: 1-888-766-8044
Disclaimer: Please note that some
parts are based on availability. The brand names
listed above are guidelines; the exact brand name
may not be available at the time we build your
engine. Pricing is deemed to be correct at time
of posting, but is not guaranteed. It is listed
as a guideline only. Please call us for complete
pricing on the engine built to your specific requirements.
These engines are built from our Dyno
tested and road proven packages.
Your specific engine can be Dyno tested individually for an additional cost.
Also ask about Fast Track engine testing for your engine, which is cheaper than Dyno testing!
Please be sure to read our full Disclaimer: CLICK HERE.
6/3/14 txt (140K engines & 44 yrs)
2/18/15 txt manifold
10/9/15 added pics
3/31/16 txt, bullets, moveup
9/12/16 add eng
9/13/16 txt dsclmr
7/6/17 txt, pc
* Note: When we custom build your engine,
you can choose from over 25 different colors or you can
supply the paint to have your engine painted the same color
as your car's finish!
Please note photos may vary from actual product as all our engines
are custom built.
